Canon Unveils Two PL-Mount Digital Cine Zoom Lenses

April 8, 2011 | Zoltan Arva-Toth | Lenses | 1 Comment |
News image

Canon USA has introduced two advanced-design PL-mount lenses that address the emerging 4K production standards. Designated as the Canon FK14.5-60 wide-angle cine zoom and the Canon FK30-300 telephoto cine zoom, both of these lenses are more compact and lightweight than contemporary PL-mount lenses and both feature a totally new Canon optical design that virtually eliminates focus breathing. The wide-angle FK14.5-60 (pictured) maintains its T2.6 maximum aperture over the entire focal range, and boasts a high MTF even wide open. (T-stops are prectically f-stops corrected for light loss caused by the absorbance and reflectance of the actual lens elements employed.) As you will probably have guessed, these lenses are not meant for the amateur videographer, although some of the technology used to make them may eventually trickle down to lenses used by mere mortals.

Canon Press Release

Canon U.S.A. Introduces Two PL-Mount Digital Cine Zoom Lenses With Full 4K Image Format Performance

Based Upon a New Optical Design Platform, These Precision-Matched Wide-Angle and Telephoto Cine Zoom Lenses Feature Multiple Imaging Enhancements

LAKE SUCCESS, N.Y., April 7, 2011 – Canon U.S.A., Inc., a leader in digital imaging, today introduced two advanced-design PL-mount lenses that address the emerging 4K production standards. Designated as the Canon FK14.5-60 wide-angle cine zoom and the Canon FK30-300 telephoto cine zoom, these precision-matched lenses incorporate breakthrough Canon optical designs that simultaneously optimize and enhance multiple imaging attributes while minimizing optical aberrations and distortions. Both lenses are also more compact and lightweight than contemporary PL-mount lenses and both feature a totally new Canon optical design that virtually eliminates focus breathing. As digital cinematography continues to accelerate for theatrical motion pictures, TV movies, episodic dramas, commercials, and other forms of digital high-resolution production, professionals will require the very best in performance and image quality. By already performing in accordance with emerging 4K production image format standards, both of the new Canon PL-mount cine zoom lenses inherently ensure the very highest performance in contemporary 2K and HD digital motion imaging.

“Both the Canon FK14.5-60 wide-angle cine zoom lens and the FK30-300 telephoto cine zoom lens are engineered to meet the most demanding overall imaging requirements of the latest large-format single-sensor digital cinematography cameras, and the creative requirements of the most discerning cinematographers, producers, and directors. Canon’s new wide-angle FK14.5-60 and telephoto FK30-300 PL-mount lenses will be on display at the 2011 NAB Show along with many other Canon HD lenses and advanced imaging products in booth # C-4325 in the Central Hall of the Las Vegas Convention Center, April 11-14.

“The 2K and HD digital production formats are firmly established in the global marketplace today, while 4K resolution is poised to further propel the imaging quality of digital cine production. Anticipating this exciting evolution in digital acquisition guided Canon’s developments of a new optical platform in recent years to meet the current and future imaging needs of high-resolution camera sensors,” explained Larry Thorpe, national marketing executive, Broadcast and Communications division, Canon U.S.A. “Canon has extrapolated a new optical platform – first seen during NAB 2009 on a working prototype 8K lens – to bring to market these two new PL-mount lenses. Advanced glass materials, exotic new optical coatings, and new computer-design techniques were all employed to achieve significant overall optical performance in these two lenses.”

Digital Cinematography for Feature Films

Canon’s new FK14.5-60 wide-angle cine zoom lens and FK30-300 telephoto cine zoom lens are both engraved with large, highly visible focus scales for convenient film-style operation. Both also have a common 136 mm front diameter for use with industry-standard optical accessories. The location, diameter, and rotation angle of the lens gears are also identical, which further facilitates convenience in exchanging lenses on-set.

The wide-angle FK14.5-60 maintains its T2.6 maximum aperture over the entire focal range, and with the virtual absence of focus breathing offers new freedom in exploring novel picture creation. The lens preserves a high MTF (modulation transfer function) at wide-open apertures, exhibits well-controlled light distribution across the image plane, and greatly curtails ghosting and veiling glare artifacts from strong light sources. These attributes combine to help ensure superb contrast under a wide range of scene-lighting conditions, help maximize the image-creation capabilities of the current top-of-the-line single-sensor digital cinematography cameras. The telephoto FK30-300 complements the wide-angle FK14.5-60 in larger studios while also servicing many outdoor shots with exceptionally vivid imagery.

TV Movies, Episodic Series, and Commercial Production

The focal ranges offered by the wide-angle FK14.5-60 and the telephoto FK30-300 cine zoom lenses are designed to flexibly address most of the needs of contemporary HDTV episodic program production. The short depth of field, high sensitivity, superb contrast ratio, and excellent picture sharpness of both lenses are designed to provide producers of TV movies, episodic (drama) series, commercials, and music videos with the creative imaging flexibility needed to fulfill a myriad of potential story-telling objectives. Both lenses are equipped with precision back-focus adjustments to expedite lens-camera set-up, which is especially useful in multi-camera TV production environments. The mechanism is concealed beneath a cover plate. In addition, both lenses provide superb control over geometric distortion to prevent visible anomalies when shooting at extreme wide angles on large studio sets that contain extended straight edges.

About Canon U.S.A., Inc.
Canon U.S.A., Inc., is a leading provider of consumer, business-to-business, and industrial digital imaging solutions. Its parent company, Canon Inc. (NYSE:CAJ), a top patent holder of technology, ranked fourth overall in the U.S. in 2010†, with global revenues of more than US $45 billion and is listed as number six in the computer industry on Fortune Magazine’s World’s Most Admired Companies 2010 list. Canon U.S.A. is committed to the highest levels of customer satisfaction and loyalty, providing 100 percent U.S.-based consumer service and support for all of the products it distributes. At Canon, we care because caring is essential to living together in harmony. Founded upon a corporate philosophy of Kyosei – “all people, regardless of race, religion or culture, harmoniously living and working together into the future” – Canon U.S.A. supports a number of social, youth, educational and other programs, including environmental and recycling initiatives. Additional information about these programs can be found at http://www.usa.canon.com/kyosei. To keep apprised of the latest news from Canon U.S.A., sign up for the Company’s RSS news feed by visiting http://www.usa.canon.com/rss.
