Lightroom 3 Review

June 15, 2010 | Jon Canfield | Software Reviews | Rating star Rating star Rating star Rating star Half rating star

Introduction

Close on the heels of Adobe's release of Photoshop CS5, Lightroom 3.0 is now available. Lightroom, unlike Photoshop, is built from the ground up for photography and the unique workflow that we have as digital photographers. Rather than dealing with 3D, vector graphics, and other general graphics tasks that aren't of interest to most of us, Lightroom distills the features down to what is important - image management and optimization. While Lightroom 2 is a popular option for many, the latest release adds some new features that improve the overall workflow and quality of output.

Importing

At it's heart, Lightroom is part digital asset manager - you need to import your images into the Lightroom database, either by copying them, or referencing them at a location on your drive, before you can use the tools or output your images. Importing in Lightroom 2 was a straight forward process, but it did have room for improvement. Performance wasn't that impressive, and if you had different groups of images on a card, you needed to perform multiple imports to put these files in different locations.

With version 3, Importing has received a complete face-lift and gained some nice new features (Figure 1)

Lightroom 3Figure 1

Import now fills your screen by default (you can collapse this to a smaller window if you like).  Thumbnail size of images in the preview area is adjustable so you can take a closer look if you want to filter the images out prior to import. On the right side of the import window is a Destination panel that lets you select where your images are placed. You can drag the selection bar up or down to choose the location (or double click on the destination folder). Lightroom will display the subfolders that will be created as well as the number of images each folder will contrain.

On feature I've found very useful is the Presets option. Once I've selected the settings I want to use, clicking on Save Current Settings as a New Preset will give me the options to save these settings for future use.

Tethered Capture

Related to importing, Lightroom 3 now includes a Tethered Capture option that lets you shoot directly into Lightroom. Currently the app supports cameras from Canon and Nikon, and Adobe says they expect this list to grow as testing is completed on other camera models.

To shoot tethered, select File > Tethered Capture > Start Tethered Capture. A settings dialog box will be displayed (Figure 2) where you can enter session information, what type of metadata is written with the images, file naming, and where the files will be saved.

Lightroom 3Figure 2

Once your settings are done, you'll see the Tethered Capture Controller. If you have multiple cameras connected, you can select which camera to control, the current settings of the camera, whether to apply develop presets as the images are captured, and a capture button (Figure 3).

Lightroom 3Figure 3

Finally, Lightroom 3 will now import your video files into the library. Support for video is minimal - unlike Apple's Aperture, you'll need an external player/editor to do anything with your videos, but being able to manage them is a good start. Hopefully, Adobe will add more in this area as more dSLR's include a video capability.

Image Processing

At the heart of Lightroom is the image processing component - the Develop module. Lightroom 3 uses the same new processing engine as Adobe Camera Raw in Photoshop CS5. The new processing version is not backward compatible, so you won't be able to go back to a previous version of Lightroom or ACR if you use the new process, but there is really no reason to want to. The results from the new version are superior in every respect to the previous version, especially when it comes to lens correction and noise handling. Lightroom will not update your images automatically, so to help with finding what version your images are using, you can select Library > Find Previous Process Photos. This will filter your library to show only those images with the old process.  You can review what changes will be made to the image when updating, and like other editing tasks in Lightroom this is non-destructive so you can always go back if you want (Figure 4).

Lightroom 3Figure 4

By default, the new process is sharper with better color fidelity and lower noise. In looking at several hundred images, I didn't find a single image that didn't benefit from updating the process.

Noise reduction has been improved, with more control over the edge detail when using luminance and color noise adjustments. Typically, luminance noise reduction reduces the sharpness in your image. With the Detail and Contrast controls here, you can recover much of that sharpness (Figure 5).

Lightroom 3Figure 5

Sharpening is also improved with less likelihood to generate halos or distortion on edges. The preview controls in the sharpening module are still available and can make your choices easier to refine.

Film Grain is a new feature. It's ironic that as digital photographers we work so hard to eliminate noise in our images, and then we'll go to a utility to add grain back in. If you've always assumed that noise and grain are the same thing, you'll be surprised at the difference between the two. Film grain varies in size and shape while noise is uniform. With the new film grain feature (Figure 6), you can adjust the amount, size, and roughness to simulate different film types. This effect works best with black and white images.

Lightroom 3Figure 6

Vignetting has also been updated to be more darkroom like (Figure 7). In the previous version of Lightroom, vignettes were applied as dark or light painting with an equal value in the selected areas. In Lightroom 3, there is a Style option with Highlight or Color priority, or you can select the previous Paint style. Highlights is a new adjustment, available with the two new styles and controls how the vignette interacts with the highlights in your image.

Lightroom 3Figure 7a

Lightroom 3Figure 7b
