Sensor

Sensor Type

1/2.3 type (7.82mm) Exmor R CMOS sensor

Number of Pixels (Effective)

Approx. 20.4 Megapixels

Number of Pixels (Gross)

Approx. 21.1 Megapixels

Lens

Lens type

ZEISS Vario Sonnar T* Lens, 15 elements in 10 groups (including 1 super ED glass element, 2 ED glass element and 3 aspheric element)

F-number (Maximum Aperture)

F2.8 (W) - 6.3 (T)

Focal length (f=)

f=4.3-215mm

Focus Range (From the Front of the Lens)

iAuto: AF (W: Approx. 1cm (0.03 ft.) to Infinity, T: Approx. 240cm (7.87 ft.) to Infinity) / Program Auto: AF (W: Approx. 1cm (0.03 ft.) to Infinity, T: Approx.240cm (7.87 ft.) to Infinity)

Optical Zoom

50x (Optical Zoom during movie recording)

Clear Image Zoom (Still Image)

Still Image: 20M Approx.100x / 10M Approx.142x / 5M Approx.200x / VGA Approx.810x / 15M(16:9) Approx.100x / 2M(16:9) Approx.270x; Movie: Approx. 100x

Filter Diameter

Yes (φ55)

Digital Zoom

20M Approx. 200x / 10M Approx. 284x / 5M Approx. 400x / VGA Approx. 810x / 15M (16:9) Approx. 200x / 2M (16:9) Approx. 540x

Iris diaphragm

7 blades

Screen

Screen Type

7.5cm (3.0type) (4:3) / 921,600 dots / Xtra Fine / TFT LCD

Adjustable Angle

Up by approx. 90degrees, down by approx. 60degrees

Display Selector (Finder/Lcd)

FINDER/MONITOR (not automatically)

MF Assist Magnification

8.1x, 16.2x

Viewfinder

Screen Type/Number of Dots

Electrical (0.5cm (0.2 type), 201.600dots equivalent)

Field Coverage

100%

Brightness Control

Manual (5 steps)

Camera

Image Processing Engine

Yes (BIONZ X)

Steadyshot

Optical

Focus Mode

Single-shot AF;DMF;Manual Focus;Continuous AF(Advanced sports & Movie Only)

Focus Area

Wide;Center;Flexible Spot (S/M/L)

LOCK ON AF

Yes

Light Metering Mode

Multi Pattern;Center Weighted;Spot

Exposure Compensation

+/- 2.0 EV, 1/3 EV step

ISO Sensitivity (Still Image)(Recommended Exposure Index)

Auto(ISO80-3200, selectable with upper / lower limit), 80/100/125/160/200/250/320/400/500/640/800/1000/1250/1600/2000/2500/3200, Multi-Frame NR:Auto(ISO80-3200),100/200/400/800/1600/3200/6400 /12800

ISO Sensitivity (Movie)

Auto (ISO80-3200, selectable with upper / lower limit),80/100/125/160/200/250/320/400/500/640/800/1000/1250/1600/2000/2500/3200

Minimum Illumination (Movie)

Auto: 4lux (Shutter Speed 1/30)

WB Micro Adjustment

G7-M7,A7-B7

Shutter Speed

iAuto (4 - 1/4000) / Program Auto (1 - 1/4000) / Aperture Priority (8 - 1/2000) / Shutter Priority (30 - 1/4000) / Manual (30 - 1/4000)

Aperture

iAuto (F2.8-F6.3 (W)) / Program Auto (F2.8-F6.3 (W) ) /Aperture Priority (F2.8-F8.0(W)) / Shutter Priority (F2.8-F6.3(W)) / Manual (F2.8-F8.0 (W))

Image Control

Quality(Fine / Standard)

Noise Reduction

Long exposure NR;high ISO NR:Normal/Low;Multi Frame NR:Auto, ISO100-12800

Dynamic Range Functions

Off, Dynamic Range Optimizer (Auto/Level 1-5), Auto High Dynamic Range: Off, Auto Exposure Difference, Exposure difference Level (1.0-6.0EV, 1.0EV step)

Shooting Mode

Program Auto;Aperture Priority;Shutter Speed Priority;Manual Exposure;MR(Memory Recall) 1,2;Movie Mode(Program Auto,Aperture Priority,Shutter Speed Priority,Manual Exposure);Panorama;Scene Selection;Intelligent Auto;Superior Auto

Scene Selection

High Sensitivity;Night Scene;Handheld Twilight;Night Portrait;Landscape;Portrait;Soft Skin;Anti Motion Blur;Beach;Snow;Fireworks;Advanced Sports Shooting;Gourmet;Pet Mode

Continuous Shooting Speed (maximum) (with max. recording pixels)

Approx. 10 fps (for up to 10 shots)

Self-Timer

Off / 10sec. / 2sec. / portrait 1 / portrait 2

Drive Modes

Single;Continuous shooting;Self-timer;Self-timer(cont.);Self-portrait;Cont.-bracketing;White balance bracketing

Panorama (Shooting)

Intelligent Sweep Panorama (supports 360 format)

Creative Style

Standard, Vivid, Portrait, Landscape, Sunset, Black & White, Sepia

Auto Image Rotation

Yes

Metering Mode

Multi Pattern;Center Weighted;Spot

Number of Recognised Scenes

Still Image: Superior Auto: 44 / iAuto: 33; Movie: 44

Minimum Illumination

Auto: 4lux (Shutter Speed 1/30)

Exposure Control

Yes

Built-in Flash Red-Eye Correction

On / Off

Flash

Flash Mode

Flash Off / Autoflash / Fill-flash / Slow Sync. / Advanced Flash /Rear Sync.

Flash Type

Built-in, manual pop-up

AF Illuminator

Auto / Off

Flash Range

ISO Auto: Approx. 0.5m to 8.5m (1.64 ft. to 27.89 ft.) (W) / Approx. 2.4m to 3.5m (7.87 ft. to 11.48 ft.) (T), ISO3200: up to Approx. 12.0m (39.37 ft.) (W) / Approx. 5.1m (16.73 ft.) (T)

Recording

Compatible Recording Media

Memory Stick Duo;Memory Stick PRO Duo;Memory Stick PRO Duo (High Speed);Memory Stick PROHG Duo;Memory Stick Micro Memory Stick Micro (Mark2);SD Memory Card;SDHC Memory Card;SDXC Memory Card;microSD Memory Card microSDHC Memory Card microSDXC Memory CardRecording Format

Still Images: JPEG ( DCF, Exif, MPF Baseline ) compliant, DPOF compatible

Recording Format (Movie Audio)

AVCHD:Dolby Digital(AC-3) 2ch(Dolby Digital Stereo Creator), MP4: MPEG-4 AAC-LC 2ch

Colour Space (Still)

sRGB

Movie Recording Mode (NTSC)

AVCHD: 28M PS(1,920x1,080/60p) / 24M FX(1,920x1,080/60i) / 17M FH(1,920x1,080/60i) / 24M FX(1,920x1,080/24p) / 17M FH(1,920x1,080/24p),MP4: 12M(1,440x1,080/30fps) / 3M VGA(640x480/30fps)

Panorama (Recording)

Intelligent Sweep Panorama (supports 360 format)

Number of Recording Pixels (Image Size)

3:2mode:18M(5,184×3,456) / 8.9M(3,648×2,432) / 4.5M(2,592×1,728) / 4:3mode:20M(5,184×3,888) / 10M(3,648×2,736) / 5M(2,592×1,944) / VGA / 16:9mode:15M(5,184×2,920) / 7.5M(3,648×2,056) / 2.1M(1,920×1,080) / 1:1mode:15M(3,888×3,888) / 7.5M(2,736×2,736) / 3.7M(1,920×1,920) / Sweep Panorama:Wide(7,152×1,080/4,912×1,920) /Standard(4,912×1,080/3,424×1,920) / Sweep Panorama:360 (11,520×1,080)

Interface

Input and Output Terminals

Multi/Micro USB Terminal, Hi-Speed USB (USB2.0), Micro HDMI

Power

Power Source

DC3.6V (supplied battely) / DC5.0V (supplied AC Adoptor)

Battery System

NP-BX1

Power Consumption (Camera Mode)

Approx. 1.4W (EVF:Approx. 1.1W)

USB Charge/USB Power Supply

Yes (Power supply during shooting/playback requires separately sold AC-UD10.)

Battery Life(Still Images)

Still Images: Approx. 300 / Approx. 150min (EVF:Approx. 380 / Approx. 190min); Movies (actual shooting): Approx. 50min (EVF: Approx. 55min). (In [MP4 12M] mode, max. continuous shooting time is approx. 15 min. and max. file size is 2GB); Movies (continuous shooting): Approx. 85min (EVF: Approx. 95min). (In [MP4 12M] mode, max. continuous shooting time is approx. 15 min. and max. file size is 2GB. )

Others

Photo Creativity

Yes

Shooting Functions

Face Detection;Grid Line;Smile Shutter;Digital Level Gauge (roll);WB Bracket;MF Assist;Micref Level

Playback Functions

BRAVIA Sync(Control for HDMI);9/25-frame index view;Auto Orientation;Slide Show;Forward/Rewind (Movie);Delete;Protect;Motion Shot Video

Operating Temprature

0 degrees C. - +40 degrees C. / 32 degrees F. - 104 degrees F.

Size & Weight

Dimensions (W x H x D)

129.6 x 93.2 x 103.2 mm (5 1/8 in. x 3 3/4 in. x 4 1/8 in.)

WEIGHT (CIPA COMPLIANT)

Approx. 652g (1lb 7.0oz.) (Battery and Memory Stick DUO are included) / Approx. 625g (1lb 6.0oz.) (Body Only)

What's In The Box

• Rechargeable Battery Pack NP-BX1
• AC AdaptorAC-UUD12
• Micro USB cable
• Shoulder Strap

• Shoe Cap
• Lens Cap
• Instruction Manual
