DxO Labs have added  a new exposure time measurement setup to DxO Analyzer 5, providing the first automated solution for measuring exposure time, shutter lag, ERS delay, vertical blanking, frame time, frame rate, and missing frames for both still and video CMOS-based cameras. All CMOS sensors feature an ERS, which introduces many kinds of artifacts and distortions that particularly affect moving objects, resulting in wobble or jello effects, skew, smear, or partial exposure. DxO Analyzer v5 uses advanced image processing technologies to deliver a precise characterization of ERS distortions. The new setup combines the DxO LED Universal Timer, shutter triggers, and software, all developed by DxO Labs to deliver automatic test shot processing.

Dxo Press Release

DxO Analyzer v5 introduces the first automated solution for characterizing Electronic Rolling Shutter for video and still cameras

July 16, 2013 - DxO Labs announces the immediate availability of DxO Analyzer v5’s new exposure time measurement setup. With this new feature, DxO Analyzer v5, the reference solution for measuring still and video image quality, now provides the first automated solution for measuring exposure time, shutter lag, ERS delay, vertical blanking, frame time, frame rate, and missing frames for both still and video CMOS-based camera products, whether equipped with a touch-screen or a standard mechanical shutter.

Exclusive DxO Analyzer Universal Timer

All CMOS sensors feature an Electronic Rolling Shutter (ERS), which introduces many kinds of artifacts and distortions that particularly affect moving objects, resulting in wobble or jello effects, skew, smear, or partial exposure.

DxO Analyzer v5 uses advanced image processing technologies to deliver a precise characterization of ERS distortions. The new setup combines the DxO LED Universal Timer, shutter triggers, and software, all developed by DxO Labs to deliver the unique advantage of automatic test shot processing.

The DxO LED Universal Timer features high-count and small-cell LED arrays that deliver exposure time measurement precision up to 10µs. A unique touch-screen trigger enables testing automation for smartphones, tablets, and other touch-screen-based devices, making measurements much more reliable and easier to perform than with any other competitive solution.

Coupled to the DxO LED Universal Timer, DxO Analyzer v5 scans the shots and automatically provides a test report with all ERS measurement data, including automatic detection and counting of missing and duplicate frames — another important attribute of video exposure characterization.

“With this new feature, we continue to expand our ability to bring to the industry the most reliable and productive solution for characterizing video capture,” said Nicolas Touchard, DxO Labs’ VP of Marketing, Image Quality Evaluation.

An extensive, standards-compliant measurement solution

DxO Analyzer v5 is a complete measurement solution providing in-depth RAW and RGB image quality analysis and diagnosis for any image capture device. It offers a range of solutions for reliably evaluating, diagnosing, and fine-tuning digital camera products and prototypes in any industry that uses image capture devices, including photography, mobile phone, automotive, surveillance, medical imaging, machine vision, aerospace, and defense.

DxO Analyzer v5 measures all relevant image quality parameters: color, resolution (MTF) and sharpness, dynamic range, exposure, noise, and most optical aberrations (including distortion, chromatic aberrations, and light shading). It includes test lab specifications and equipment, documentation, automated analysis software, and supporting services.

With its unique image stabilization, motion artifact, and 3D camera measurement features, DxO Analyzer v5 offers a set of advanced video camera testing features to help camera engineers, designers, and marketers better understand video product performance.

DxO Analyzer v5 measurements comply with all relevant ISO, CIPA, I3A, IEEE, and SMIA imaging standards, with a particular focus on the latest video-related standards such as the CIPA Image Stabilization measurement method.

About DxO Labs

DxO Labs develops image processing technologies. In addition to its DxO Optics Pro, DxO FilmPack, and DxO ViewPoint products for Mac and Windows, designed for serious and demanding photographers, the company also licenses diverse solutions for the principal actors in the imaging industry:

Embedded technologies for real-time image processing, destined for camera and cameraphone manufacturers;
Image quality evaluation and measurement tools, destined for specific imaging industries (e.g., camera module manufacturers, sensor vendors, and processor vendors) as well as for photography journalists and photo experts.

For more information, visit DxO Labs’ website at www.dxo.com
