Panasonic Lumix DMC-FX01
PMA 2006: The Panasonic Lumix DMC-FX01 is announced today. 6 megapixels, 28mm wide-angle Leica optical zoom lens, 2.5 inch LCD, available in March.
Panasonic UK Press Release
Panasonic’s launches the Lumix DMC-FX01 - the world’s smallest camera[1] with 28mm wide angle lens[2]
The world renowned Panasonic Lumix range offers sophistication in technology and style, evidence of which lies in the new 6.0 megapixel Panasonic FX01. The latest addition to the award winning FX series boasts a whole host of features including a 28mm wide angle LEICA DC lens with 3.6x optical zoom, all encompassed within a beautifully slim and compact design - thanks to the incorporation of an Extra High Refractive Index Lens. This new lens allows photographers to easily capture a large group of people, or expansive architectural structures and landscapes with dynamic width and rich perspective. The lens part of the DMC-FX01 comprises of seven elements in six groups, incorporating four aspherical lenses to generate high optical performance. The zoom ratio can be extended up to 5x in 3megapixel resolution mode with minimal deterioration thanks to the Extra Optical Zoom. By using the central part of the CCD, this powerful zooming function allows you to easily capture and magnify distant subjects.
Shaken, not blurred
Panasonic is the first manufacturer to have successfully incorporated Optical Image Stabiliser (OIS) into its compact cameras – a feature strongly appreciated worldwide and now considered to be a standard requirement of photography. O.I.S minimizes the jitter from shaky hands that causes many photos to look blurred by shifting the O.I.S lens unit to keep the optical axis aligned straight against the CCD, to ensure images are captured with supreme clarity and sharpness.
Not one to rest on its laurels, Panasonic has enabled the DMC-FX01 to shoot at a maximum sensitivity setting of ISO 1600, with its new High Sensitivity Mode. This ingenious mode reduces image blur caused by subject movement - particularly indoors - by shooting at fast shutter speeds. Made possible by the mixed-pixel read out method of the CCD, users can now enjoy good quality 4”x6” prints of moments that would otherwise be lost. Whilst the resolution will not be as high in this mode, High Sensitivity is the difference between getting a shot or not at all.
Panasonic Lumix offers solutions for both major causes of blurred images – O.I.S when you are moving, and High Sensitivity when the subject is moving. Thanks to Panasonic, you can now take clear and beautiful images in various situations.
The Venus Engine Plus LSI: High performance at low energy consumption
The DMC-FX01 incorporates the Venus Engine Plus LSI which allows you to take 320 pictures on one charge, providing high performance image processing while consuming only 70% of the energy compared with the Venus Engine II. Spontaneous moments can easily be captured thanks to a 1.6 second start up time (20% less than the predecessor DMC-FX9) and a 0.005 second shutter release time lag (the time taken between pressing the button on the camera and the photo being taken.)
Additionally, the consecutive shooting performance boasts the capability of sequential shots at a rate of 3 frames per second at full resolution[3]. The unlimited consecutive shooting function allows you to take photos in succession up to the capacity of the memory card or built in memory. The speed in which photos are taken is dependent on the memory card.
Auto focus… fast
The DMC-FX01 really will work hard to ensure you capture every moment important to you. The various AF methods can be selected according to the shooting environment and the position of the subject: 5 point, 3 point high-speed, 1-point high speed, 1-point normal-speed and spot. The remarkably quick AF response time, especially in the 1-point high speed AF mode, achieves outstanding focusing with both speed and precision. Panasonic has also included an AF assist lamp, providing further assistance in low light situations where focusing can be difficult.
Motion pictures at your fingertips
In addition to standard VGA(640x480) motion image recording, as featured on the DMC-FX9, the DMC-FX01 also records stunning full-size movies in wide-aspect VGA (840x480) at 30fps, enabling you to view your recordings on a widescreen television.
Create a scene with two new scene modes
The DMC-FX01 boasts two new scene modes to ensure your photos look the way you intended, in addition to the fourteen available on the predecessor DMC-FX9[4]. The first is the previously mentioned High Sensitivity Mode, great for taking photos of moving subjects, for example young children and pets who may not quite grasp the concept of sitting still! The DMC-FX01 is also perfect for underwater photography, for use with the Marine case (available separately), thanks to the new ‘underwater’ mode. Panasonic’s existing fourteen modes are portrait, soft skin, scenery, sport, night portrait, night scenery, food, party, candle, fireworks, starry sky, snow and baby mode. Panasonic’s unique ‘baby’ mode has now doubled its appeal with the ability to set two birthdays for two children. When shooting in Baby mode 1 or 2, the relevant child’s age at the time of image capture is automatically recorded onto the image, allowing you to hold on even closer to the precious moments in your children’s lives.
Stand out from the crowd with the large LCD’s new High Angle Mode
The Lumix DMC-FX01 boasts a 207K pixel high resolution, 2.5” large LCD. The pixel-mixed readout method performed by the CCD automatically increases the brightness level of the live image on the LCD, which greatly facilitates shooting in low light situations.
Panasonic is the first manufacturer to offer the new High Angle LCD function to a digital still camera LCD. This new mode makes the FX01’s LCD display extremely easy to view from low angles, for example, when holding the camera up high to take pictures over a crowd. The difficulties faced when shooting in bright outdoors situations are also overcome by the Power LCD function, which boosts the backlighting of the LCD by 40%.
The high resolution LCD also allows both a full display of your images in up to 25 thumbnails on a multi-split screen and the ability to date search an image with the new Calender Display Mode.
The Panasonic Lumix DMC-FX01, the world’s smallest camera with 28mm wide angle lens is superior in technology and superior in style. Available in March. For further information, please visit www.panasonic.co.uk
DMC-FX01 Specifications
Colour: S-Silver, K-Black
Dimensions (W x H x D)
Approx. 94.1 x 51.1 x 24.2 mm ( 3.70 x 2.01 x 0.95 inch)
Weight
Approx. 132g. (0.29 lb)
?
Approx. 160g with Battery and SD Memory Card (0.35 lb)
Camera Effective Pixels
6-megapixel
Image Sensor
1/2.5”, 6.37 Mega Total Pixels CCD Primary Color Filter
Optical Zoom
3.6x
Extra Optical Zoom
4:3 Aspect Ratio: 5.0x for 3Mega, 2Mega, 1Mega, 0.3Mega
3:2 Aspect Ratio: 5.0x for 2.5Mega
16:9 Aspect Ratio: 5.0x for 2Mega
Digital Zoom
4 x
( Max. 14.6 x combined with Optical Zoom without Extra Optical Zoom)
(Max. 20x combined with Extra Optical Zoom)
Focal Distance
f=4.6-16.8mm (35mm Equiv.: 28-102mm)
Lens
LEICA DC VARIO-ELMARIT
7 elements in 6 groups
(4 Aspherical Lenses / 4 Aspherical surfaces)
Aperture
Wide: F2.8 / F5.6 (2 steps) Tele: F5.6 / F11 (2 steps)
Optical Image Stabilizer
MEGA O.I.S. (Mode1/ Mode2)
Focusing Area
Normal: 50cm – infinity
Macro/Simple/Motion image : Wide 5cm/Tele 30cm – infinity
AF Metering
1 point/1-point high speed/3-point high speed/5-point/Spot
Focus
Auto Focus System, Normal/Macro (Dial)
AF Assist Lamp
Yes
ISO Sensitivity
Auto/80/100/200/400 (High Sensitivity Mode:800-1600)
White Balance
Auto/Daylight/Cloudy/Halogen/White Set
?
White Balance Adjustment ( 150K step, -1500 - +1500 K) (except for auto set)
Exposure
Program AE
Exposure Compensation
1/3 EV step, -2 - +2 EV
Backlight Compensation
Yes (at simple mode)
Auto (AE) Bracketing
+/- 1/3 EV -1EV step, 3 frames
Light Metering
Intelligent Multiple
Scene Mode
Dial: Normal Picture, Simple , Macro
SCN mode (Portrait, Soft Skin, Scenery, Sports, Night Portrait, Night Scenery, Self-portrait, Food, Party, Candle Fireworks, Starry Sky, Snow, Baby1, Baby2, High Sensitivity, Underwater) Motion Image, Playback
Shutter Speed
8-1/2000 sec
Starry Sky Mode: 15,30, 60 sec
Self Timer
10 sec / 2sec
Auto Review
1sec/3sec/zoom
Review
1x / 4x / 8x
Picture Adjustment
Natural, Standard, Vivid
Colour Effect Mode
Cool, Warm, Black & White, Sepia
Recording Format
Still Image:
JPEG(Design rule for Camera File system, based on Exif 2.2 standard),
DPOF corresponding
Picture with audio: JPEG (Design rule for Camera File system, based on Exif2.2 standard)+ QuickTime
Motion Image:
QuickTime Motion JPEG
Recording Image Size
Still Image:
4:3 Aspect Ratio: 2816 x 2112 pixels, 2048 x 1536 pixels, 1600 x 1200 pixels
1280 x960 pixels, 640 x 480 pixels
3:2 Aspect Ratio: 2816 x 1880 pixels, 2048 x 1360 pixels
16:9 Aspect Ratio: 2816 x 1584 pixels, 1920 x 1080 pixels
Motion Image:
4:3 Aspect Ratio: 640 x 480 pixels, 320 x 240 pixels
16:9 Aspect Ratio: 848 x 480 pixels
Image Quality
Fine / Standard
Motion Image
4:3 Aspect Ratio: 640 x 480 pixels, 320 x 240 pixels 30 fps, 10 fps
16:9 Aspect Ratio: 848 x 480 pixels 30 fps, 10 fps
Max. recording time depends on Memory Card Capacity
Burst Shooting Mode
Full-Resolution Image, 3 frames/sec or 2 frames/sec
Full-resolution: Max. 8 images (Standard mode), Max 6 images (Fine Mode)
Unlimited consecutive shooting
?Yes
Still Image Rec. with Audio
5 sec
Audio Dubbing
Max. 10sec
Real-time histogram
Yes
Composition Guide line
Yes
Scene Mode Help Screen
Yes
Auto Angle Detection
Yes
Economy mode
Yes
Built-in-Flash
Auto, Auto/Red-eye Reduction, Slow Sync./Red-eye Reduction, Forced On/Off
0.6 - 4.0m (Wide/ISO Auto), 0.3 - 2.0m (Tele/ISO Auto)
High Sensitivity Mode: 0.8-5.7m (Wide), 0.8m-2.8m (Tele)
LCD Monitor
2.5” Polycrystalline TFT LCD Display (207K Pixels)
Field of View : approx. 100%
Power LCD mode, High Angle mode
Playback mode
25-thumbnail display, 9-thumbnail display, Calendar Display
zoomed playback (16x max.),
Image Rotation, Slide show (Duration is adjustable, also manually controllable),
Playback of favourite pictures
Resizing (selectable number of pixels), trimming, protection, DPOF print setting ?
OSD language
English,German,French,Italian,Spanish,Japanese
Recording Media
SD Memory Card, MultiMediaCard
Microphone
Yes
Speaker
Yes
Interface
DC Input, AV Output (NTSC/PAL), USB
Direct Print
PictBridge
Power
Li-ion Battery Pack (3.7V, 1150mAh) (Included)
AC Adaptor (Input: 110-240V AC) (Optional)
Battery life (approx.)
320 pictures (CIPA Standard*1)
Included Software
LUMIX Simple Viewer
ArcSoft PhotoBase, ArcSoft PhotoImpression,
ArcSoft Panorama Maker
USB Driver
Standard Accessories
Battery Charger, Battery Pack, Battery carrying case, SD Memory Card (16 MB)
AC Cable, AV Cable, USB Connection Cable, Strap, CD-ROM
*1. Shooting conditions: 23°C with 50% humidity; LCD on; using the enclosed SD Memory Card; starting to shoot 30 seconds after turning on the power; shooting once every 30 seconds with the flash in full operation for every other shot; changing the zoom setting from telephoto to wide, or wide to telephoto, for each shot; and temporarily turning the power off after each 10 shots (long enough to lower the battery temperature).
*1MB=1million byte, usable capasity will be less
*Some accessories are not available in some countries.
*The use of recorded or printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe upon the rights of the copyright holder.
*Leica is a registered trademark of Leica Microsystems IR GmbH.
[1] For a digital still camera with optical zoom, as of February 14, 2006
[2] 35mm film camera equivalent, at wide angle
[3] Max eight images in standard mode/six images in fine mode
[4] The sixteen scene modes does not include macro mode
